LM393DT LM393 393 IC ชิพ SMD Comparators

Product Category : Analog Comparators
Product : Driver ICs - Various
Mounting Style : SMD/SMT
Package/Case : SOIC-8
Number of Channels : 2 Channel
Output Type : CMOS, DTL, ECL, MOS, TTL
Response Time : 1.3 us
Comparator Type : Differential
Supply Voltage - Min : 2 V
Supply Voltage - Max : 36 V
Operating Supply Current : 600 uA
Output Current per Channel : 18 mA
Vos - Input Offset Voltage : 5 mV
Ib - Input Bias Current : 250 nA
Minimum Operating Temperature : 0 C
Maximum Operating Temperature : +70 C
Brand : STMicroelectronics
Height : 1.5 mm
Length : 5 mm
Width : 4 mm
ชื่อสินค้า: LM393DT SMD
